Roofing Systems

Roofing Systems can be confusing. That is why Storage Building Central has made all our roof panels easy to understand and read. No roof is made the same and it is the difference between a roof that leaks and a roof that last generations. Our Storage Building Experts are pro’s when it comes to ensuring your building always has the right roof installed.

Panel-Loc

Panel-Loc™ is a low rib (5/8”) panel that is best used for post frame barns and buildings, as well as residential roofing. Panel Loc™ is available in 26 and 29 gauge steel.

Panel-ploc-width-coverage
panel loc light gauge roof

Panel Loc Image

General Information

General Information

  • Panel rib height: 5/8″
  • Panel coverage:  36″ wide
  • Panel length:  26″ to 45′ in .5″ increments
  • Tensile strength:  80,000 psi minimum
  • Substrate:  Varies by option; Galvalume® (AZ-50) or galvanized (G90)
  • Gauge:  26 and 29
  • Recommended roof slope:  3:12 pitch minimum or greater

Available Options

Available Options

Thrifty Prime Fluropon®
MCA certification  #229SPL  #229PPL
26 gauge thickness .0178″ min .0185″ min N/A
29 gauge thickness .0138″ min .015″ min .015″ min
Tensile strength 80,000 psi minimum 80,000 psi minimum 80,000 psi minimum
Substrate Varies Galvalume® Galvalume®
Gauge 26 and 29 26 and 29 29 only
Coating CentralGuard® CentralGuard® Fluropon® 70% PVDF
Primer .1-.2 mils top .2-.3 mils top .2-.3 mils top
Paint thickness .5-.6 mils top .7-.8 mils top .7-.8 mils top
Warranty 20 yr. limited paint integrity 40 yr. paint and 20 yr. Galvalume® substrate 40 yr. paint and 20 yr. Galvalume® substrate
Colors 10 21 1 – Copper Metallic Only

Panel-Loc Plus

Panel-Loc Plus™ is a low rib (3/4”) panel which provides durable performance with an added striation on top of the rib that gives it even more strength. Panel-Loc Plus™ gives agricultural and light commercial projects, as well as residential roofs, the protection of steel with an attractive appearance. It is available in 26 and 29 gauge steel, as well as aluminum.

Panel-plocplus-width-coverage
panel-loc-plus

Panel Loc Plus Image

General Information

General Information

  • Panel rib height: 3/4″
  • Panel coverage: 36″ wide
  • Panel length: 26″ to 45′ in .5″ increments
  • Tensile strength: 80,000 psi minimum
  • Substrate: varies by option; Galvalume® (AZ-50) or galvanized (G90)
  • Gauge: 26 and 29
  • Recommended roof slope: 3:12 pitch minimum or greater

Available Options

Available Options

Thrifty Prime Fluropon®
MCA certification #229SPLP  #229PPLP
26 gauge thickness .0178″ min .0185″ min N/A
29 gauge thickness .0138″ min .015″ min .015″ min
Tensile strength 80,000 psi minimum 80,000 psi minimum 80,000 psi minimum
Substrate Varies Galvalume® G90
Gauge 26 and 29 26 and 29 29 only
Coating CentralGuard® CentralGuard® Fluropon® 70% PVDF
Primer .1-.2 mils top .2-.3 mils top .2-.3 mils top
Paint Thickness .5-.6 mils top .7-.8 mils top .7-.8 mils top
Warranty 20 yr. limited paint integrity 40 yr. paint and 20 yr. Galvalume® substrate 40 yr. paint
Colors 10 21 15

Horizon-Loc

Horizon-Loc™ is a durable concealed fastener roof system with easy snap together installation.  This architectural  panel system uses minimally visible fasteners, giving your building a clean, attractive finish.  The panel’s easy snap-on ribs attach rapidly with  no hand seaming, making installation less expensive than traditional standing seam.

Panel-hloc-width-coverage
horizon loc roof panel

Horizon Loc Plus Image

General Information

General Information

  • Panel rib height: 1″
  • Panel coverage: 16″ wide
  • Panel length: 3′ to 40′  in 1″ increments, maximum recommended length = 35′
  • Tensile strength: 50,000 psi minimum
  • Substrate: varies by option; Galvalume®
  • Gauge: 26
  • Recommended roof slope: 3:12 pitch or greater

Available Options

Available Options

Prime Fluropon®
MCA certification  #229SHOR  #229PHOR
26 gauge thickness .0185″ min .0185″ min
Tensile strength 50,000 psi minimum 50,000 psi minimum
Substrate Galvalume® Galvalume®
Gauge 26 26
Coating CentralGuard® Fluropon® 70% PVDF
Primer .2-.3 mils top .2-.3 mils top
Paint Thickness .7-.8 mils top .7-.8 mils top
Warranty 40 yr. paint and 20 yr. Galvalume® substrate 40 yr. paint and 20 yr. Galvalume® substrate
Colors 20 1 – Copper Metallic Only

R-Loc

R-Loc™ is a 26 gauge commercial panel that is an excellent choice for projects that require commercial grade performance.  R-Loc™ is designed to maximize the potential of your structures, specifically the steel frame.  With its added purlin bearing rib, you can count on easier installation and a more pleasing appearance.

Panel-rloc-width-coverage
r-loc-roof-panel

R Loc Image

General Information

General Information

  • Panel rib height: 1 1/4″
  • Panel coverage: 36″ wide
  • Panel length: 26″ to 45′ in .5″ increments
  • Tensile strength: 80,000 psi minimum
  • Substrate: Varies by option; Galvalume®
  • Gauge: 26
  • Recommended roof slope:1/2:12 or greater roof slopes and ideal for low pitch commercial roofs

Available Options

Available Options

Thrifty Prime Fluropon®
MCA certification  #229SRLOC  #229PRLOC
26 gauge thickness .0178″ min .0185″ min .0185″ min
Tensile strength 80,000 psi minimum 80,000 psi minimum 80,000 psi minimum
Substrate Varies Galvalume® Galvalume®
Gauge 26 26 26
Coating CentralGuard® CentralGuard® Fluropon® 70% PVDF
Primer .1-.2 mils top .2-.3 mils top .2-.3 mils top
Paint thickness .5-.6 mils top .7-.8 mils top .7-.8 mils top
Warranty 20 yr. paint integrity 40 yr. paint and 20 yr. Galvalume® substrate 40 yr. paint and 20 Yr. Galvalume® substrate
Colors 8 17 1 – Copper Metallic only

BarnMaster

BarnMaster® corrugated panels are an economical option for any agricultural application. Central States® Manufacturing, Inc. offers 1 1/4 and 2 1/2 profiles depending on your needs. Longer lead times may apply on some orders as this panel is manufactured in our Arkansas facility. Protect your investment with BarnMaster® corrugated panels.

Barnmaster-profiles
barnmaster-roof-system

Barn Master Image

General Information

General Information
Panel rib height: 1/4″ or 1/2″

Panel coverage: 24″ wide

Panel length: Stock lengths of 6′, 8′, 10′, 12′, 14′, 16′, 18;’ and 20′.

Gauge: Both profiles are available in 29 gauge or economy gauge.

Substrate: 29ga is available in either Galvalume® (AZ-55) or galvanized (G90)

Substrate:Economy gauge is available in galvanized (G40)

Central Span

The Central Span™ panel has a traditional flat pan, vertical rib appearance, often preferred by traditional architects for superior appearance and performance. Central-Span™ roofs meet the requirements for a wide range of roof slopes, shapes, loads, weather and related conditions. It has many of the features required for architecturally shaped roofs.

Panel-centralspan
CentralSpan-roof-system

Central Span Image

General Information

General Information

  • Standing seam height: 2″
  • Panel coverage: 16″
  • Panel length: 36″ to 52′ in .5″ increments
  • Tensile strength: 50,000 psi minimum
  • 14 ENERGY STAR rated Fluropon® colors
  • Substrate: Galvalume®
  • Gauge: 24 (22ga special order only – contact your sales rep for details)
  • Mechanically seamed
  • Recommended minimum slope:  1/4 :12 or greater
  • Minor striations in the flat.
  • Clip has a full 3″ of thermal movement.
  • 90° or 180° seam.
  • Factory applied sealant.
  • One of the highest uplift ratings in the industry.

Available Options

Available Options

Fluropon®
MCA Certification #229PSPAN
24 Gauge Thickness .0230″ min
Tensile Strength 50,000 psi minimum
Substrate Galvalume®
Gauge 24
Coating Fluropon® 70% PVDF
Primer .20 mils top
Paint Thickness .80 mils top
Warranty 40 yr. paint, 30 yr. chalk and fade, 20 yr. Galvalume® substrate
Colors 14

M-LOC

M-Loc™ is a structural roof and wall panel that can be installed directly over purlins or joists.  The M-Loc™ panel is available in 26 gauge.  This commercial panel has long served customers with lasting durability in commercial type applications.

Panel-mloc
m-loc-roof-system

Central Span Image

General Information

General Information

  • Panel rib height: 13/16″every 6 inches
  • Panel coverage: 36″ wide
  • Panel length: 26″ to 45′ in .5″ increments
  • Tensile strength: 80,000 psi minimum
  • Substrate: Varies by option; Galvalume®
  • Gauge: 26
  • Recommended roof slope: 1:12 pitch or greater

Available Options

Available Options

Thrifty Prime Fluropon®
MCA certification #229SMLOC  #229PMLOC
26 gauge thickness .018″ nom .0185″ min .0185″ min
Tensile strength 80,000 psi minimum 80,000 psi minimum 80,000 psi minimum
Substrate Varies Galvalume® Galvalume®
Gauge 26 26 26
Coating CentralGuard® CentralGuard® Fluropon® 70% PVDF
Primer .1-.2 mils top .2-.3 mils top .2-.3 mils top
Paint thickness .5-.6 mils top .7-.8 mils top .7-.8 mils top
Warranty 10 yr. Paint integrity 40 yr. paint and 20 yr. Galvalume® substrate 40 yr. paint and 20 yr. Galvalume® substrate
Colors 8 17 1 – Copper Metallic only

Precision Loc

Precision-Loc® is our 24 gauge commercial/industrial wall and soffit panel.  Precision-Loc® is available with one rib (perforated or solid),  and solid flat (no ribs).

Precision-Loc-profiles1
precision-loc

Precision Loc Image

General Information

General Information

  • Panel rib height: 1″
  • Panel coverage: 12″ wide
  • Panel length: 36″ to 35′ in .5″ increments
  • Tensile strength: 50,000 psi minimum
  • Substrate: Galvalume®
  • Gauge: 24
  • Uses concealed fastener system

Available Options

Available Options

Fluropon®
MCA certification
24 gauge thickness .0230″ min
Tensile strength 50,000 psi minimum
Substrate Galvalume®
Gauge 24
Coating Fluropon® 70% PVDF
Primer .2-.3 mils top
Paint thickness .7-.8 mils top
Warranty 40 yr. paint and 20 yr. Galvalume® substrate
Colors 14 ENERGY STAR rated colors

Central Seam Plus

Central Seam Plus® is a trapezoidal standing seam system designed for commercial and architectural projects.  Central Seam Plus®’ mechanically seamed system begins and ends in the high, reducing the risk of leakage at the rake.

Panel-centralseam
central-seam-plus

Central Seam Plus Image

General Information

General Information

  • Standing seam height: 3″
  • Panel coverage: Available in:
    • 24″ with minor ribs – prepunched 6 holes or no punching
    • 18″ with minor ribs – prepunched 5 holes or no punching
  • Panel length: 5′ to 45′ in .5″ increments
  • Tensile strength: 50,000 psi minimum
  • Substrate: Galvalume®
  • Gauge: 24
  • Seam sealed with factory-applied hot melt mastic.

Available Options

Available Options

Prime Fluropon®
MCA certification  #229SCSP  #229PCSP
24 gauge thickness .023″ min .023″ min
Tensile strength 50,000 psi minimum 50,000 psi minimum
Substrate Galvalume® Galvalume®
Gauge 24 24
Coating CentralGuard® Fluropon® 70% PVDF
Primer .2-.3 mils top .2-.3 mils top
Paint thickness .7-.8 mils top .7-.8 mils top
Warranty 40 yr. paint and 20 yr. Galvalume® substrate 40 yr. paint and 20 yr. Galvalume® substrate
Colors Bare Galvalume® available with no minimum quantity; Colors may require a minimum quantity. 14

Central Loc

Central-Loc® is a snap-together trapezoidal roofing system that is an excellent choice for commercial applications.  Central-Loc® is manufactured from Galvalume® which offers two to four times the corrosion resistance of galvanized steel.

Panel-centralseam
central-loc

Central Loc Image

General Information

General Information

  • Standing seam height: 3″
  • Panel coverage:
    • 24″ with minor ribs – prepunched 6 holes or no punching
    • 18″ with minor ribs – prepunched 5 holes or no punching
  • Panel length: 5′ to 45′ in .5″ increments
  • Tensile strength: 50,000 psi minimum
  • Substrate: Galvalume®
  • Gauge: 24
  • Recommended roof slope: 1/4:12 pitch or greater
  • Seam sealed with factory-applied hot melt mastic.

Available Options

Available Options

Prime Fluropon®
MCA certification  #229SCLOC  #229PCLOC
24 gauge thickness .023″ min .023″ min
Tensile strength 50,000 psi minimum 50,000 psi minimum
Substrate Galvalume® Galvalume®
Gauge 24 24
Coating CentralGuard® Fluropon® 70% PVDF
Primer .2-.3 mils top .2-.3 mils top
Paint thickness .7-.8 mils top .7-.8 mils top
Warranty 40 yr. paint and 20 yr. Galvalume® substrate, optional weathertight performance 40 yr. paint and 20 yr. Galvalume® substrate. optional weathertight performance
Colors Bare Galvalume® with no minimum quantity;  Colors may require a minimum quantity 14

Central Snap

Central Snap® is a vertical 1 3/4″ snap-lock standing seam panel system that is sturdy and fire resistant, making it ideal for architectural and commercial applications. Installation is a snap, and its Galvalume® substrate offers two to four times the corrosion resistance of galvanized steel.  24 gauge flat sheets are also available.

Panel-centralsnap
central-snap

Central Snap Image

General Information

General Information

  • Standing seam height: 1 3/4″
  • Panel coverage: Available in 16″ and 18″ coverage with subtle striations between ribs
  • Panel length: 36″ to 52′ in .5″ increments
  • Tensile strength: 50,000 psi minimum
  • Substrate: Galvalume®
  • Gauge: 24
  • Seam sealed with factory-applied hot melt mastic.
  • Available with a 1 3/16″ notch on either end of each panel for the ease of turning under; reducing installation labor and costs.
  • Recommended minimum slope:  3:12 or greater

Available Options

Available Options

Fluropon®
MCA certification Pending
24 gauge thickness .0230″ min
Tensile strength 50,000 psi minimum
Substrate Galvalume®
Gauge 24
Coating Fluropon® 70% PVDF
Primer .2-.3 mils top
Paint thickness .7-.8 mils top
Warranty 40 yr. paint and 20 yr. Galvalume® substrate
Colors 14
